The GIGABYTE B650M GAMING WIFI is a Micro-ATX motherboard designed for AMD Ryzen™ processors, offering a blend of performance and connectivity. It supports AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors, making it suitable for gaming and productivity applications.
SPECIFICATIONS:
Socket: AM5
Chipset: AMD B650
Memory:
2 x SMD DIMM slots
Supports DDR5 ECC and Non-ECC unbuffered memory
Memory speeds supported: Up to 6400 MHz (OC) and beyond
Maximum memory capacity: 64 GB
Expansion Slots:
1 x PCIe 4.0 x16 slot
Storage:
1 x M.2 connector (PCIe 4.0 x4)
4 x SATA III ports
Networking:
1 x Realtek 10/100/1000 Mbps Ethernet port
Onboard Wi-Fi 6E 802.11ax
Audio:
8-Channel High Definition Audio
USB Ports:
4 x USB 2.0 Type-A ports
2 x USB 3.2 Gen 1 Type-A ports
Video Outputs:
1 x HDMI port
1 x D-Sub port
Form Factor: Micro-ATX
Key Features:
✅ Processor Support – AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors.
✅ Memory Capacity – Supports up to 64 GB of DDR5 memory, suitable for intensive applications and multitasking.
✅ PCIe 4.0 Ready – Equipped with a PCIe 4.0 x16 slot for high-speed graphics cards, enhancing gaming and graphical performance.
✅ Fast Storage Options – Offers an M.2 connector for fast SSD storage, supporting PCIe 4.0 x4 mode.
✅ Integrated Wi-Fi 6E – Onboard Wi-Fi 6E 802.11ax support for high-speed wireless connectivity.
✅ High-Definition Audio – Integrated 8-Channel High Definition Audio for immersive sound experiences.
✅ Networking – Realtek Gigabit Ethernet ensures stable and fast network connectivity for online activities.
✅ Multi-Display Support – Provides HDMI and D-Sub outputs for multiple display setups.
✅ Smart Fan 6 – Features multiple temperature sensors and hybrid fan headers with FAN STOP, allowing for customizable cooling solutions.
✅ Q-Flash Plus – Update BIOS without installing the CPU, memory, and graphics card.
